Core Advantages & Differentiators
Superior Multi-Jammer Interference Resilience
Powered by advanced 8-element array anti-jamming technology, this module delivers exceptional interference suppression capabilities, with an interference suppression ratio (ISR) of ≥110dBc against a single jammer, ≥100dB against 3 simultaneous jammers, and ≥90dB against up to 7 concurrent interference sources. This ensures stable, unbroken navigation even in RF-congested industrial zones, urban canyons, and high-interference field environments.
Highly Integrated Miniaturized Design
Unlike bulky split-type anti-jamming solutions, this integrated miniaturized anti-jamming GNSS module achieves an optimal balance of performance, size, and weight. With a compact 150mm x 150mm x 22.5mm form factor and a total weight of ≤720g, it is perfectly suited for weight- and space-constrained applications such as small drones and mobile robots, without compromising on anti-interference performance.
Multi-Constellation Compatibility & Cost-Effective Performance
Supporting four global navigation constellations, this antenna delivers global coverage and redundant positioning capability, ensuring reliable operation across all geographic regions. Its all-in-one design eliminates the need for separate processors and receivers, reducing integration complexity and total system cost, making it a cost-effective choice for high-volume industrial deployments.
Industrial Applications & Use Cases
This robotics high-precision GNSS antenna is optimized for compact industrial and unmanned system scenarios, including civilian and commercial drones for aerial surveying and agricultural mapping, autonomous mobile robots (AMRs) and automated guided vehicles (AGVs) for industrial automation and warehouse logistics, ground robotics for outdoor inspection and security patrol, precision agriculture equipment, and urban infrastructure inspection devices for smart city operations.
Customization & Integration Support
We partner with industrial equipment manufacturers, robotics developers, and drone system integrators to provide customized navigation solutions aligned with your application needs. Our customization services include mechanical size and mounting optimization for compact drone and robot designs, custom communication and RF interface configurations, firmware tuning for specific operating environments, low-power mode optimization for battery-powered systems, and full end-to-end integration support with your flight controller or robot motion control system.
